Auto Control Cables Manufacturing Unit
This project profile covers the establishment of an auto control cables manufacturing unit, producing flexible link motion cables for two and three wheelers, motorcycles, scooters, and other automotive applications. The unit will produce inner cores and outer spiral casings to facilitate clutch, brake, and gear control operations.
Project cost & finance
Cost of Project
figures in ₹ Lakhs
| Plant & Machinery | 17.94 |
| Furniture & Fixtures | 0 |
| Other Misc. Assets | 1 |
| Working Capital | 5.74 |
| Total | 24.68 |
|---|
Means of Finance
figures in ₹ Lakhs
| Own Contribution | 2.47 |
| Term Loan | 17.05 |
| Working Capital Loan | 5.17 |
| Total | 24.68 |
|---|
Raw materials & machinery
Machinery & equipment8
- Wire Twisting MachineBuy on Amazon ↗
Used to twist fine stranded steel wires for the inner core
- Spring winding / Casing coiling machineBuy on Amazon ↗
Used to coil closed spiral springs for outer casing
- Automatic PVC Cable Extruder MachineBuy on Amazon ↗
Used to coat the outer casing with plastic material
- Abrasive cutting off machineBuy on Amazon ↗
Used for cutting wires and cables to desired lengths
- Bench grinderBuy on Amazon ↗
Used for sharpening and general grinding work
- Spring Controlled Arbor Press MachineBuy on Amazon ↗
Used for pressing operations during assembly
- Pressure Die Casting MachineBuy on Amazon ↗
Used for casting zinc alloy lugs onto cable ends
- Packaging MachineBuy on Amazon ↗
Used for packing finished control cables
Raw materials6
- Spring steel wire carbonBuy on Amazon ↗
Used for coiling the outer spiral casing of control cables
- Medium carbon steel wireBuy on Amazon ↗
Used for forming the inner core wire rope
- Zinc AlloyBuy on Amazon ↗
Used for pressure die casting of terminal lugs and fittings
- PVC GranulesBuy on Amazon ↗
Used for plastic coating on outer casing springs
- Tin Solder / FerrulesBuy on Amazon ↗
Used for cable end fittings
- Packing materialsBuy on Amazon ↗
Used for final product packaging
Manufacturing process
- Twist fine stranded steel wires using a wire twisting machine to form the inner core and cut to specified lengths.
- Form the outer casing by coiling spring steel wire into a long closed spiral spring using a spring winding machine.
- Extrude a protective plastic layer over the outer casing spring using an automatic PVC cable extruder.
- Attach suitable metal lugs or ferrules to either end of the inner core and outer casing using a pressure die casting machine and arbor press.
- Inspect the assembled control cables for smooth mechanical movement and proper dimensions.
- Pack the finished auto control cables using a packaging machine for distribution and sale.
Market
Automotive control cables are critical components heavily consumed by the two-wheeler and three-wheeler segments. The market enjoys steady replacement demand due to regular wear and tear during vehicle operation, with consistent projected industry growth.
